Product Details
Place of Origin: CHINA
Brand Name: Screate DALA
Model Number: N3
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: standard packing, as customer demands
Delivery Time: 7 - 15 working Days
Payment Terms: T/T, etc.
Measurement Data: |
Diameter |
Application: |
Fine Wire |
Measurement: |
0.015~1mm |
Repeatability: |
±0.05μm |
Accuracy: |
±（0.00012+0.03%*D)mm |
Size: |
145*34*88mm |
Working Power Source: |
24V ±10% 40VA |
Communication: |
RS485(Mod Bus RTU)，CAN(CAN Open)，WIFI(for Data Debugging) |
Measurement Data: |
Diameter |
Application: |
Fine Wire |
Measurement: |
0.015~1mm |
Repeatability: |
±0.05μm |
Accuracy: |
±（0.00012+0.03%*D)mm |
Size: |
145*34*88mm |
Working Power Source: |
24V ±10% 40VA |
Communication: |
RS485(Mod Bus RTU)，CAN(CAN Open)，WIFI(for Data Debugging) |
Moreover, in the realm of fine wire measurement, precision becomes more pronounced as wire size diminishes. Achieving an impressive repeatability of ±0.05 µm, it ensures meticulous accuracy in every measurement.
Thanks to its motor-free design, maintenance for the system is notably simplified, eliminating the necessity for motor upkeep or replacement. This streamlined approach enhances operational efficiency and reduces downtime, ensuring seamless performance over time.
The DALA N3 can be conveniently managed via computer and cellphone, allowing for tasks such as parameter settings, measurement data management, and more.
| Model | N3 |
|---|---|
| Axis | 1-axis |
| Measurement data | diameter |
| Measurement range | 0.015~1mm |
| Repeatability | ±0.05μm |
| Accuracy | ±(0.00012+0.03%*D)mm |
| Size | 145*34*88mm |
| Working power source | 24V ±10% 40VA |
| Running temperature | 5℃~50℃ |
| Display | LED display |
| Commuincation port | RS485(Mod bus RTU),CAN(CAN open),WIFI(for data debugging) |
| Data colletion & analysis | available(DMS1000) |
| Out-of-tolerance alarm | available |
| Far-end display function | available |
