Product Details
Place of Origin: CHINA
Brand Name: Screate DALA
Model Number: CV-3000 Series
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: standard packing, as customer demands
Delivery Time: 7 - 15 working Days
Payment Terms: T/T, etc.
Measurement Type: |
Round Wire: Diameter, Ovality, Surface Quality Flat Wire: Width, Thickness ,surface Quality |
Axis And Frequency: |
2-Axis，46KHz/Axis |
Measurement Range: |
0.2~25mm |
Dimensional Accuracy: |
±2μm |
Minimum Defect Height: |
±10μm |
Measurement Type: |
Round Wire: Diameter, Ovality, Surface Quality Flat Wire: Width, Thickness ,surface Quality |
Axis And Frequency: |
2-Axis，46KHz/Axis |
Measurement Range: |
0.2~25mm |
Dimensional Accuracy: |
±2μm |
Minimum Defect Height: |
±10μm |
Multiple cameras achieves 100% surface image acquisition,and then use pre-trained machine to learn and process collected images so as to identify and clarify various defects.
| Model | CV-3025Q(1) |
|---|---|
| Measurement range | 0.2~25mm |
| Axis and frequency | 2-Axis,46KHz/Axis |
| Measurement type |
Round wire: diameter, ovality, surface quality Flat wire: width, thickness ,surface quality |
| Dimensional accuracy(2) | ±2μm |
| Minimum defect height | ±10μm |
| Minimum defect size | Related to cameras, optical lens and production line speed , minimum to size of 0.05mm can be achieved |
| Power supply | 24VDC ± 5%, Max. 84W |
| Max wire speed | Related to cameras and optical lens configuration as well as minimum defects size and colour difference inspection . related to measurement requirements , need on site adjustment. |
| Surface defects missing rate(3) | <1% |
| Surface defects detection false(3) |
<1% |
| Electrical interface |
RS485 MODBUS RTU,CAN,UDP |
| Weight | 12.5kg |
| IP grade | IP54 |
NOTE:
(1)More new products will released soon;
(2)Set average time to 0.1s and measure the ±2σvalue of the φ10mm round rod at the measurement area center;
(3)Related to measurement requirements , need on site adjustment.
